Delayed Egress

Features
Fire Alarm Contacts – Fire Alarm input at any time will cut power to the
delayed egress function and provide immediate egress.
Armed-Momentary Egress – Turning the key clockwise allows
authorized personnel to exit without alarming. At the end of the field
selectable time period (10, 20 or 30 seconds), the device will relock and
rearm.
De-Device Networking Feature – This feature allows a Delayed Egress
device to arm, alarm, reset and disarm all devices on the same circuit.
Each device will continue to operate independently for Momentary
Egress.
30 Second Delay – A 30 second delay option is available. A written
approval from the authority having jurisdiction is required. Note: A
“30 Second” decal is provided when the 30 Second Delay option is
Delayed Egress specified.
The Delayed Egress (DE) Exit Device provides a controlled egress Nuisance Delay Time – A Nuisance Delay Time helps avoid inadvertent
for openings which require Panic or Fire Exit Hardware for safe activation. The alarm will sound when the touchbar is pressed, but the
egress. It is a self contained exit device, which when armed will alarm sequence will not start unless the touch bar is held in for more
deny exit to unauthorized personnel for 15 or 30 seconds, while than the Nuisance Delay Time. Delay Time is field selectable for 0, 1, 2 or
simultaneously sounding a local or remote audible alarm. The 3 seconds.
Remote Monitoring feature will alert the security personnel that Integral Key Switch
an attempt is being made to exit the opening. After the 15 (or Arm – The Key switch provides the means to locally arm the (DE) device.
30) second delay of egress period the device will function as a
standard exit device for safe egress. Momentary Egress – The Key switch will provide temporary disarming
Operation – The device secures the door in the locked mode to allow for momentary egress (10, 20 or 30 seconds) when the device
is in the armed state. The Key switch will Disarm the device and it will
with the Red LED indicating locked status. Depressing the function as a standard exit device.
Touchbar by accident or for less than the Nuisance Delay Time
will sound the alarm without initiating the alarm sequence. Reset – During alarm sequence the device can be rearmed by the Key
Depressing the Touchbar with less than 15 pounds pressure, for Switch.
longer than the Nuisance Delay Time will initiate an irreversible Requires the use of a 1-1/4 mortise cylinder, not furnished standard.
local audible beeping tone and a visual Red indicator until the Specify when required.
device releases. After the delay egress time the lock releases and LED Status Indicator (in the device) - A color coded LED indicates Arm,
the alarm changes to a steady tone which continues to alarm Disarm and Alarm status.
until Reset. The remote monitoring contact output can be used
to alert security personnel. The person depressing the Touchbar Flashing Green – Arming
is denied egress (for 15 or 30 seconds) and security personnel Flashing Red – Armed
are alerted for quick response. Green – Unarmed
Trim – All standard device trims and functions are available, Red – Alarmed
including “03” function, Trim Lock/Unlock will function normally Off – No Power to Device (Normal Exit)
even when the delayed egress feature is armed. The Device
will only be affected when the Touchbar is depressed from the Internal Alarm – The device has a 85 db horn which will sound until the
inside. All (DE) Rim and Mortise Devices are also available with device is reset.
Electric Lock/Unlock for the outside Trim. For details see page 28. External Alarm – A set of relay contacts rated at (1 amp, 24VDC) are
Available for all Apex Series Exit Devices. provided for activating external local or remote audible/visual signaling
devices.
The Delayed Egress Devices are manufactured and tested
to exceed ANSI 156.3 and 156.24. Devices are UL Listed as a External Inhibit
Controlled Exit Device (FULA) and Special Locking Arrangements Arm/Rearm – Accepts a contact to Arm/Rearm the device.
(FWAX) category. Meets all requirements of NFPA 101. Momentary Egress – Accepts a contact to provide temporary disarming
to allow for momentary egress when the device is in the armed state.
The Momentary Egress will be engaged as long as the switch closure is
maintained.
Reset – Accepts a contact to reset the device during alarm.

24 Apex 2000 Series Touchbar Exit Devices
