Electric Latch Retraction

Available for all Series Devices
The ELR option provides remote Latch Retraction of exit ELR150 Power supply door opened
devices. Continuous duty solenoids retract the Latchbolt(s)
for momentary unlatching or continuously for dogging. The
ELR feature can be interfaced with automatic door operators,
card readers, push buttons, toggle/key switches, and fire
alarm systems.
• ELR option REQUIRES ELR150 Series Power Supply.
• UL Listed for Panic and Fire for Class II Circuitry.
• ELR can be used in combination with all Apex options ....................
including Hex Key or Cylinder Dogging. ELR option is not available
for (DE) Delayed Egress Devices.
Door Widths – ELR150 Power supply door closed
3 Device - 2-7 to 3-0 Door ELR150 Series Power Supply
4 Device - 3-1 to 4-0 Door The ELR150 Series is a power supply REQUIRED to control ELR Devices.
The Power Supply model number is determined based on the The power supply contains a Motherboard that will accept up to four
number of devices requiring electrical power. See To Order ELR150 plug-in Control Modules. Each Control Module (part #CM150-08, see
Power Supply below. page 22) controls one ELR Device and includes a Time Delay Feature.
To order: specify prefix “ELR” (e.g. ELR2108) The Time Delay provides a variable (0 - 4 minutes) Latch Retraction
period in response to a momentary input.
ELR Conversion Kit Specifications
A standard device can be retrofit to the Electric Latch • UL Listed for Class II Output.
Retraction option by ordering the kits listed below. An ELR
Conversion Kit REQUIRES an ELR150 Series Power Supply. • UL 294 - Conforms to U.L. 294 Standards incorporating enhanced
Access Control communication capabilities.
To Order: • Circuit breakers provide protection for Motherboard.
Wide Stile Devices
3-0 ELRK-3, ELRKF-3 • 115 or 230 Volt user selectable switch.
4-0 ELRK-4, ELRKF-4 • A.C. Input = 115 Volts at 1 Amp.
Narrow Stile Devices • Battery Back-up / Power Tap available (see page 22).
3-0 NELRK-3, NELRKF-3 • LED Indicator - Provides clear indication that power is available to
4-0 NELRK-4, NELRKF-4 the supply.
Note: Power may be supplied through a 4-wire continuous circuit hinge • Keyed Cabinet - To maintain safety and security, each Power
(furnished by others). Supply is equipped with a preinstalled key-cylinder.
Solenoid Specifications • Includes lockable box with key lock.
Current Pulse (2 seconds max.) ....................... 4.75 Amp. • Dimensions: 16” W x 14” H x 6” D.
Continuous ......................................... 3.6 VDC / 0.8 Amp. • Weight: 15 lbs.
To Order: ELR150 Power Supply –
The model number is determined based on the number of devices requiring electrical power.
ELR150 – Power Supply, no control modules
ELR151 – Power Supply including (1) control module to control (1) exit device
ELR152 – Power Supply including (2) control modules to control (2) exit devices
ELR153 – Power Supply including (3) control modules to control (3) exit devices
ELR154 -–Power Supply including (4) control modules to control (4) exit devices
To order power supply with Battery Backup: specify suffix BT (e.g. ELR151BT)

Apex 2000 Series Touchbar Exit Devices 21
