Windstorm And Hurricane Code Devices

Compliance – HC2100, HC2200, HC2300, HC2800 Series Devices and
HC822, KRHC822 Mullions comply with the Florida Building Code
including the High Velocity Hurricane Zone. The Miami-Dade County
Product Control Division has approved these devices to be used in Miami-
HC2100 , HC2200, Dade County and other areas where allowed by the Authority Having
HC2300, HC2800 Series Devices HC822, Jurisdiction (AHJ). Product Control NOA No. 09-0218.09 is issued for these
KRHC822 Mullions devices which expires on September 30, 2014.
The Hurricane Devices have passed the structural tests as per South To see the NOA documentation online:
Florida Building Code Protocol. These tests are designed to provide http://www.miamidade.gov/buildingcode/pc-search_app.asp and type
sufficient resistance to high wind forces and windborne debris. in the NOA number: 05-1102.12 under the Product Search Application
The devices provide a high level of security for door openings link.
even if hurricane rated door components are not required. A brief
description of the test is provided below.
Static Air Pressure Test – Simulates wind loading by evenly ANSI Function Device No. Trim No.
distributing air pressure to the face of the door assembly in Exit Only HC2101, FLHC2101 1701
positive and negative directions. The door assembly must not have 01 (cover plate) HC2201, FLHC2201 2001
excessive deflection or deformation and must remain secure in the HC2301, FLHC2301 4901
chamber. HC2801, FLHC2801
Missile Impact Test – Simulates impacts created by wind driven Dummy Trim HC2102 1702A
debris by impacting the exterior face of the doors with a 2 x 4 02 HC2202 2002C
board at 50 feet per second. The board must not pass through the HC2302 4902A
doors and the doors must remain secure in the chamber. HC2802
Key Retracts HC2103, FLHC2103 C03
Cyclic Wind Pressure Test – Simulates wind gusts by
repeating cycles of positive and negative air pressure to 03 Latchbolt HC2203, FLHC2203 1703
HC2303, FLHC2303
2003
determine that the integrity of the door assembly is not HC2803, FLHC2803 4903
compromised with the Missile Impact Test. The door M4903A
assembly must not have excessive deflection or deformation
and must remain secure in the chamber. Key Locks / HC2105, FLHC2105 1705A
Unlocks
HC2205, FLHC2205
2005A
Component Approval – These devices are approved as 05 Thumbpiece HC2305, FLHC2305 M1705A
components to be used with any 16 gage Single or a Pair of HC2805, FLHC2805 M2005A
Hollow Metal Doors and Frames holding a current Notice of Key Locks / HC2108, FLHC2108 4908A
Acceptance (NOA). The lowest Design Pressure Rating of the doors Unlocks HC2208, FLHC2208 V4908A
or components shall apply. 08 Lever / Knob HC2308, FLHC2308 M4908A
HC2808, FLHC2808 VM4908A
Door Open- Device Design Double Cylinder HC2110, FLHC2110 4910A
ing Series Pressure 10 Inside Key HC2310, FLHC2310 V4910A
Single Door Locks / Unlocks M4910A
Lever / Knob VM4910A
Rim Device 4’-0” W HC2100 80 PSF No Cylinder HC2114, FLHC2114 4914A
8’-0” H Lever / Knob HC2214, FLHC2214 M4914A
14
Surface Vertical 4’-0” W HC2200 80 PSF Always Active HC2314, FLHC2314
Rod Device 8’-0” H HC2814, FLHC2814
Mortise Device 4’-0” W HC2300 60 PSF No Cylinder HC2115, FLHC2115 1715A
8’-0” H Thumbpiece HC2215, FLHC2215 2015C
15
Concealed Vertical 4’-0” W HC2800 80 PSF Always Active HC2315, FLHC2315 M1715A
Rod Device 8’-0” H HC2815, FLHC2815 M2015C
Pair Of Doors • Trims with the Prefix “M” are for 2300 Series Devices only.
• 2000 Series Trim not available with 2800 Series Device.
Two Rim Devices 8’-0” W HC2100 x 80 PSF • “10” Function is handed.
with Mullion 8’-0” H HC822,
KRHC822
Two Surface 8’-0” W HC2200 x 80 PSF
Vertical Rod Device 8’-0” H HC2200 Device Specifications and Options Page
Rim Exit Devices and Trims ...................................................................................4,5
Mortise Device x 8’-0” W HC2300 x 60 PSF
Concealed Vertical 8’-0” H HC2800 Surface Vertical Rod Devices and Trims .........................................................6,7
Rod Device Mortise Devices and Trims....................................................................................8,9
Two Concealed 8’-0” W HC2800 x 80 PSF Concealed Vertical Rod Devices and Trims ..................................................16,17
Vertical Rod Device 8’-0” H HC2800
HC822 & HCKR822 Mullions ................................................................................18

20 Apex 2000 Series Touchbar Exit Devices
