2860
Series
Senior Swing

Ordering Information How-to-order 2860 Series
Operator will be shipped with:
Select installation type - Standard motor gearbox (1 LH & 1 RH)
2863 - Standard control box (2 ea)
- Header (at specified length - 72˝ standard)
Specify arm - 2-3/4˝ pivot point
3-3/4˝ (Offset pivoted) Arm (3077OP) - Wood and machine screw pack
2-3/4˝ (Center pivoted) Arm (3077CP) unless options listed below are selected.
3-3/4˝ (Center pivoted) Arm (3077CP)
Specify hand
RH
LH

Specify header/length
HL__ (Specify length 65˝ to 98˝)
Specify finish
Standard Anodized Finish ______________
Aluminum or Dark Bronze

Operator options

Stops*
Pair Positive Mechanical Stop (POS)
Pair Panic Breakaway Stop (BKY)
*Available with Center Pivoted installations only

Table of sizes

Door width
65˝ 96˝
1651mm 2438mm

2863
Minimum door width

Indicates recommended range of door width for operator.
NOTE: For all Senior Swing Series
Independent Pair – Width per leaf 32-1/2˝ minimum to 48˝ maximum

G90 LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 01/18
