2860
Series
Senior Swing

Accessories

Motor Gearbox Mount Brackets

2860-3454 2860-375 2860-275 2860-3018
Motor gearbox Mounting Bracket Mounting Bracket Rear Mounting Bracket
n Senior swing n Motor gearbox mounting n Motor gearbox mounting n Motor gearbox mounting
n Handed bracket for 3-3/4˝ offset pivot, bracket for 2-3/4˝ center pivot bracket
butt hinge or center pivot with installations n Rear bracket
n Driving mechanism for operator finger guard installations n Front bracket
n Provides maximum 15 lbs n Front bracket
opening force

Control Box Header End Cap

2860-3462 2860-3572HL 2860-334
Control box Mounting Header Header End Caps
n Electronic controlling device for n Pair door, two operators n With openings for wiring
Senior Swing n Specify length 65˝ to 98˝
maximum
n Standard

Arms

2860-3077CP 2860-3077OP 2860-3077OPCM
Center Pivot Arm Offset Pivot Arm Offset Pivot Arm Assembly
n Center pivot installations only n Offset pivot or butt hung n Offset arm with track and
n Used with overhead concealed installations only concealing channel
operators and center pivoted n Used with overhead concealed n Includes 3072 Concealing
doors operators Channel, 168 Slide Channel and
30770P offset pivot arm
