2860
Series
Senior Swing

Features

The 2860 SENIOR SWING by LCN is an ADA door operator that is a two-in-one swing
door operator. SENIOR SWING operator when activated, opens doors automatically for
wheelchair access, yet allows for manual operation for regular pedestrian traffic.

Certifications Grade 1 - ANSI A156.19, UL325/228, UL1998, Fasteners Wood and machine screw packs
ADA, 100 Hour Salt Spray, Meets BAA - Buy Mounting Independent pair, overhead concealed,
American Act center pivot, offset pivot, butt hinge
Handing Handed
Arms Offset Pivot Arm or Center Pivot Arm
Door Width n Minimum combined door with 52˝ - 96˝ Finishes/Colors/ n Anodized Aluminum
n Simultaneous pair - width per leaf 26˝ Powder Coat n Anodized Dark Bronze
minimum to 48˝ maximum
Warranty 2 years

Special Customized installation templates or products may be available to solve unusual applications.
Templates Contact LCN Product Support for assistance.

MOUNTING HANDING FINISH COVER ARM FUNCTION
SURFACE MOUNT SIMULTANEOUS PAIR
SURFACE MOUNT INDEPENDENT PAIR
CONCEALED INDEPENDENT PAIR
SURFACE MOUNT SINGLE DOOR CONCEALED SIMULTANEOUS PAIR NON-HANDED STANDARD ANODIZED STANDARD (SINGLE LEVER) OFFSET PIVOT BUTT HINGE ARM
DOUBLE EGRESS (PUSH/PULL)
REGULAR (DOUBLE LEVER)
CONCEALED SINGLE DOOR
CENTER PIVOT ARM
HANDED*
METAL
* For double egress only.
AVAILABLE
NOT AVAILABLE

G85
LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 01/18
