2850
Series
Senior Swing

Ordering Information How-to-order 2850 Series
Operator will be shipped with:
Select installation type - Standard motor gearbox (1 LH & 1 RH)
2853 - Standard control box
- Companion cable
Specify arm - Header (at specified length - 72˝ standard)
3-3/4˝ (Offset pivoted) Arm (3077OP) - 2-3/4˝ pivot point
2-3/4˝ (Center pivoted) Arm (3077CP)
3-3/4˝ (Center pivoted) Arm (3077CP) - Wood and machine screw pack
unless options listed below are selected.
Specify hand
RH
LH

Specify header/length
HL__ (Specify length 52˝ to 98˝)
Specify finish
Standard Anodized Finish ______________
Aluminum or Dark Bronze

Operator options

Stops*
Pair Positive Mechanical Stop (POS)
Pair Panic Breakaway Stop (BKY)
*Available with Center Pivoted installations only

Table of sizes

Door width
52˝ 96˝
1524mm 2438mm

2853
Minimum door width

Indicates recommended range of door width for operator.
NOTE: For all Senior Swing Series
Simultaneous Pair – Width per leaf 26˝ minimum to 48˝ maximum.

G84 LCN Door Control Catalog
