ELECTRONIC ACCESS CONTROL COMPONENTS ELECTROMAGNETIC LOCKS
DORMA EMLSG360 & EMLSG365 MORTISE
ELECTROMAGNETIC LOCKS
—

Low-profile mortise locks for Features
sliding doors. . Up to 750 lb (340 kg)
holding force (EMLSG360).
The EMLSG360 mini . Up to 300 lb (136 kg) holding
electromagnetic lock is force (EMLSG365).
specifically designed to provide a . Low energy consumption.
secure hold (up to 750 lb holding . Field selectable voltage 12/24
force) on sliding doors. VDC.
. MOV surge protection.
The compact EMLSG365 micro
electromagnetic lock, with up to . Hardened steel armature nut.

300 lb holding force, is designed . Built-in remote bond alert EMLSG360 Mortise
as an even lower profile magnet (RBA)—EMLSG360 only. for Sliding Doors
for sliding doors, cabinets, and . No residual magnetism.
jewelry cases and small . Low-profile design.
enclosures.
Finish
Aluminum: 628
(Clear Anodized)

EMLSG365 Mortise
for Sliding Doors

NOTE: When installed on access-controlled egress door assemblies, per NFPA101,
must use Push to Exit labeled manual release device. DORMA push-button models
PBEP, PB72, or PB73 are recommended.

HOW TO ORDER EMLSG360/
EMLSG365 SERIES
—

Series
Specialized
EMLSG — Electromagnetic Lock
EMLSG 360 628

Low Profile Mortise, — 360 628 — Clear Anodized
Sliding Doors, 700 lb Aluminum
Compact Mortise, — 365 Finish
EMLSG360/EMLSG365 Sliding Doors, 300 lb
Typical Installation Model

22 DORMA
