ELECTRONIC ACCESS CONTROL COMPONENTS ELECTROMAGNETIC LOCKS
EML310TP & EML320TP Electromagnetic Locks with Encoded Armature Plate

This intelligent magnet . LSS—Lock status sensor
recognizes its own armature (includes LED).
plate, preventing anyone . Field selectable
from tricking the magnet voltage—12/24 VDC.
with a separate plate. Each . Adjustable keyhole mounting.
individually encoded armature . MOV surge protection.
plate is registered to match . No residual magnetism.
its own electromagnetic lock. . Self-drilling tek™ fasteners.
Two independent relay outputs . Easy-access wiring cavity.
allow for lock status and alarm . Stabilizing 4-bolt mounting
status for local and/or remote (8-bolt for EML320TP). EML320TP Double Outswinging Interior
indication. . Adjustable re-lock time delay. or Perimeter Doors without Mullion
. 628 brushed anodized
Features
. Up to 1500 lb (680 kg) aluminum lock body finish.
holding force.
. Unrecognized armature
Listings & Approvals
plate alarm.
. Built-in time delay for instant . UL/CUL listed for
use on fire doors
release with adjustable re- rated up to 1 hr,
lock. EML310TP Single Outswinging
. Alarm time setting. UL294 Listed. Interior or Perimeter Doors
. ANSI/BHMA
. Individually encoded
156.23,
armature.
Grade 1 listed. NOTE: When installed on access-controlled egress door assemblies, per NFPA101,
must use Push to Exit labeled manual release device. DORMA push-button models
PBEP, PB72, or PB73 are recommended.
EML310/310TP & EML320/320TP Finishes & Options
HOW TO ORDER EML310/

310TP & EML320/320TP Finishes . L brackets.

. Door position sensor retrofit
SERIES Plated kit—DPR15 (EML310) or
— . Brass: 605 (Bright) or 606 . Split armature kit.
DPR25 (EML320).
Options
Door Position (Satin)
— & Tamper Sensor . Bronze: 613 (Oxidized Satin) . Magnet housing cover
DPTS . Chrome: 625 (Bright) or 626
Bond Alert w/Door wraps—MCW310 or MCW320
BADPTS — Position & Tamper (Satin) (standard with plated
Sensor
Split Armature finishes).
SAP — Plate (EML310) Painted
Series DP — Door Position . Bronze: 691 (Dull) Options
Sensor
Electromagnetic Bond Alert w/Door . Black: 693 . DP—Door position sensor
EML — Locks BADP — Position Sensor . Gold: 696 (Satin) (retrofit kits available)
EML 310 628 NOTE: Lock body supplied in 628. All . BA DP—Bond alert/door
position sensor combination
other finishes supplied as a cover wrap.
Single Door, — 310 605 . DP TS —Door position sensor
1500 lb and tamper switch
Double Door, — 320 606 Optional Mounting Accessories . BA DP TS—Bond alert/door
1500 lb 613 . Angle brackets.
Single Door, — 310TP Plated . Armature plate holders. position sensor combination
Encoded Armature, 625 and tamper switch
1500 lb 320TP 628 . Filler bars.
Double Door, Painted . Glass door brackets.
Encoded Armature, Model 691 . Spacers.
1500 lb . Top jamb Z bracket kits for
693
inswinging doors.
NOTE: All finishes other than 628 are 696 . (EML310 only—reduces
supplied as a cover wrap.
Finish holding force by half).
. Armature bolts.

DORMA 17
