ELECTRONIC ACCESS CONTROL COMPONENTS ELECTROMAGNETIC LOCKS
DORMA EML310 & EML320
MULTIPURPOSE ELECTROMAGNETIC LOCKS
—

Quick installation for enhanced . 628 brushed anodized
building security. aluminum lock body.
. Adjustable keyhole mounting.
Several standard features make . Built-in time delay (instant
these magnets amongst the release with adjustable re-
hardest workers in the industry. lock, programmable from
The adjustable mounting bracket 0–110 seconds).
has been enhanced with keyhole . Field selectable
mounting to support the voltage—12/24 VDC.
magnet’s weight during initial . Convenient plug-in wiring
installation, freeing the installer’s terminals.
. Easy-access wiring cavity.
hands to affix the magnet
mounting screws. The removable . Stabilizing 4-bolt mounting
cavity cover offers quick, easy (8-bolt for EML320). EML310 Single Outswinging
access to wiring. Both models . MOV surge protection. Interior or Perimeter Doors
feature a built-in, adjustable . No residual magnetism.
time delay with instant unlock . Low energy consumption.
and delayed re-lock (up to 110 . Hardened steel armature nut.
seconds), which can be . Self-drilling tek™ fasteners.
controlled by any standard
switching device. Listings & Approvals
. UL/CUL listed under
Features their continuing
. 1500 lb (680 kg) reinspection
holding force. programs and
. Bond Alert (BA), Door conforms to standards UL 10C
Position Sensor (DP), and and GWXT positive pressure Larger LED Size for Better Visibility
(Bond Alert versions only)
Tamper Switch (TS) options. fire testing, 1 hour fire rated
. Larger LED size for better UL294.
visibility (Bond Alert . ANSI/BHMA
versions only). 156.23, Grade 1
listed. NOTE: When installed on access-controlled egress door assemblies, per NFPA101,
must use Push to Exit labeled manual release device. DORMA push-button models
PBEP, PB72, or PB73 are recommended.

EML320 Double Outswinging
Interior or Perimeter Doors without Mullion

16 DORMA
