ELECTRONIC ACCESS CONTROL COMPONENTS ELECTROMAGNETIC LOCKS
DORMA EML375 SURFACE MICRO
ELECTROMAGNETIC LOCKS
—

Ideal for small enclosures. Finishes

The compact size offers secure Plated Finishes
locking for cash drawers, . Brass: 605 (Bright)
machinery access covers, vending or 606 (Satin)
. Bronze: 613 (Oxidized Satin)
machines, filing cabinets and
many other applications. 300 lb . Chrome: 625 (Bright)
of holding force makes this or 626 (Satin)
electromagnetic lock incredibly EML375 Swinging Doors
strong for its size. Painted Finishes on Small Enclosures
. Bronze: 691 (Dull)
Features . Black: 693
. Up to 300 lb (136 kg) . Gold: 696 (Satin)
holding force.
. Low-profile design. NOTE: Lock body supplied in 628. All
. Low energy consumption. other finishes supplied as a cover wrap.
. Field selectable
Optional Mounting Accessories
voltage—12/24 VDC. . Top Jamb Z Bracket Kits.
. MOV surge protection.
. Glass door brackets.
. Hardened steel armature nut.
. Armature plate holder.
. 628 Brushed Anodized
. Spacers.
Aluminum finish.
. Contributes to U.S. Green . Magnet housing cover wraps—
MCW375 (standard with
Building Council, LEED MR plated finishes). EML375 Typical Installation
®
Credits 2.1, 4.1, 4.2, and 5.1.
NOTE: When installed on access-controlled egress door assemblies, per NFPA101,
must use Push to Exit labeled manual release device. DORMA push-button models
PBEP, PB72, or PB73 are recommended.
Specifications EML375
Housing Dimensions 13/16" D × 1-1/2" H × 6-17/32" L HOW TO ORDER
(20.6 mm × 38.1 mm × 165.9 mm) EML375 SERIES
(including 1/8" (3.2 mm) mounting bracket) —
Armature 3/8" D × 1-1/4" H × 5-1/8" L Finish
Plate Dimensions (9.6 mm × 31.8 mm × 130.2 mm)
696 — Gold
Voltage Field selectable 12/24 VDC
Tolerance ±10% Painted 693 — Black
Power/Current Max 0.36 A @ 12 VDC Plated 691 — Dull Bronze
Requirements Max 0.18 A @ 24 VDC Clear Anodized
Holding Force Up to 300 lb 628 — Aluminum
Wiring Requirements 2 wires—power input 626 — Satin Chrome
625 — Bright Chrome
NOTE: DORMA recommends frame reinforcement and our filtered,
regulated DC voltage PS600 Series power supplies. 613 — Oxidized Satin
Bronze
Series 606 — Satin Brass
Electromagnetic
EML — Locks 605 — Bright Brass
EML 375 628

Single Door, 300 lb — 375
NOTE: All finishes other than 628 are
Model supplied as a cover wrap.

DORMA 19
