ELECTRONIC ACCESS CONTROL COMPONENTS ELECTRIC STRIKES
DORMA ES74F HEAVY DUTY
ELECTRIC STRIKES
—

Ideal for fire-rated or heavy-duty . Unique anti-vibration design
applications. prevents manipulation.
. Tamper-resistant guard
The ES74F electric strikes are concealed behind the door
designed with a unique built-in frame increases strength and
anti-vibration feature, a saddle- prevents manipulation by tool
mounted housing, and a tamper- attack.
resistant guard for increased . Heavy-duty solid cast stainless
strength and durability. steel housing design.
Crossed wires are never a . Energy efficient coil design.
problem, as the coil is not . Dual monitor switch (optional).
polarity-conscious. . Modular plug-in wire
connectors for fast hook-up.
Features . Non-handed. Tamper-resistant guard concealed
. 1500 lb (680 kg) holding . Standard mounting tabs, behind the door frame increases
force. shims, and fasteners included. strength and prevents manipulation
. Accommodates 1/2" (12.7 . 630 stainless steel finish. ES74F by tools or probes
mm), 5/8" (15.9 mm), or 3/4"
(19.1 mm) latch projection Listings & Approvals

(pullman design not included). . UL1034 listed for
. Horizontal adjustment (up to burglary
1/4" or 6.4 mm) relieves side- resistance.
load pressure, ensuring proper . 1-1/2 hour fire-
latch alignment. rated.
. Saddle-mount housing design
for enhanced strength and HOW TO ORDER ES74F SERIES
durability. —
Voltage
ES74F Specifications Series 24V — 24 VAC/DC
Mode Voltage Current Duty Sound Amps Ohms Electric Strike — ES 12V — 12 VAC/DC
Fail 12 AC Intermittent Buzz .15 61 ES 74F 24V 630
Secure 12 DC Continuous Silent .20 61
Heavy-Duty, Fire-rated — 74F Satin — 630
Fail 24 AC Intermittent Buzz .07 215 Mortise Strike, Metal Door Stainless
Secure 24 DC Continuous Silent .11 215 Model Finish

Intermittent duty = energized less than 1 minute with duty ratio 1:5.
Continuous duty = energized 1 minute or more

Available Items
ES74F Electric Strikes
Item Description
ES74F 12V 630 Heavy duty, fire-rated cylindrical strike, 12 V, 90 minute fire-rated
ES74F 24V 630 Heavy duty, fire-rated cylindrical strike, 24 V, 90 minute fire-rated

14 DORMA
