2810
Series
Senior Swing

Accessories

Channels Installation Accessories

2810-3072 2810-168 2810-384B 2810-384F
Concealing Channel Slide channel Door Stop Breakaway Door Stop Fixed
n Used to conceal arm n Offset pivot or butt hinge n Allows in-swinging door to n Prevents out-swinging door
in overhead concealed installations only swing out in case of emergency from swinging in
applications n Mounts in top rail of door n Disables operator in breakaway n For center pivoted installations
n For offset pivot installations n Allows arm to slide mode. only
only
n For center pivoted installations
n If ordering separately specify only
length and hand

Pivots

2810-3107 2810-107 2810-12 2810-11A
Bottom Pivot Assembly Bottom Pivot Body Filler Plate Blank Spindle Plate
n Includes pivot body, pivot post n For center pivoted installations n Completes length of header n Hides bottom of motor gearbox
and bottom pivot plate box n Completes header box
n For overhead concealed, center n Cutout allows for motor
pivoted installations
gearbox shaft
n Includes; 2810-107, 2810-110 n For 2-3/4˝ center pivot
and 2810-117 installations

2810-110 2810-117 2810-11B
Pivot Post Bottom Pivot Plate Spindle Plate
n Connects pivot body to bottom n Applied to floor for center n Hides bottom of motor gearbox
pivot plate for center pivoted pivoted installations n Completes header box
installations
n Cutout allows for motor gearbox shaft
n For 3-3/4˝ offset pivot, butt hinge or center pivot with
finger guard installations

G77
