P. 76
4040XP
Series
Accessories
Installation Accessories cont.
4040XP-30 4040XP-61 4040XP-419 4040XP-62A
CUSH Shoe Support Blade Stop Spacer PA Flush Panel Adapter Auxiliary Shoe
n Provides anchorage for fifth n Required to lower parallel arm n Provides horizontal mounting n Requires a top rail of 7˝
screw used with CUSH arms, shoe to clear 1/2˝ (13 mm) surface for parallel arm shoe on (178 mm)
where reveal is less than blade stop single rabetted or flush frame n Shoe replaces -62PA for
3-1/16˝ (78 mm) n Optional n Optional parallel arm mounting of
n Optional regular arm with overhead
holder/stop
n Optional
4040XP-54
Snap-On Cover Clip
n Used to secure 4040XP-72
Plastic Cover to cylinder body
B44 LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 07/17
