4630
Series
Auto Equalizer

Ordering Information

How-to-order 4630 Series closers
Closer will be shipped with:
Specify finish - Standard cylinder
Standard Powder Coat __________ - Standard metal cover
Aluminum, Dark Bronze, Statuary, Light Bronze, Black, Brass - Standard arm
- Track roller
- Standard track
Closer options - Wood and machine screw pack
unless options listed below are selected
Cylinder Assembly
CS (concealed on/off switch)
(separate key switches suggested)
Finishes
Custom Powder Coat (RAL)__________________
Plated Finish, US_____________________________

Screw pack
TB*, Wood & Machine Screw (TBWMS)
TORX Machine Screw (TORX)
TB* & TORX Machine Screw (TBTRX)
*Specify door thickness if other than 1-3/4˝.

Special template
ST- ________

Table of sizes

n Non-Sized 4630 series cylinder is adjustable from size 1 through size 4 and is shipped set to size 3
n Closing power of 4630 Series closers may be increased 50%

Exterior (and Vestibule) door width Interior door width
36˝ 36˝ 38˝ 48˝
914mm 914mm 965mm 1219mm
size 2 size 3
4631 4631
Minimum door width Minimum door width

Indicates recommended range of door width for closer size. NOTE: Minimum door width 36˝ (914 mm).

G41
