4630
Series
Auto Equalizer

Accessories

Cylinders Cover

4631-3971 4631-3071 4631-3071CS 4630-72MC
Cast Iron Cylinder Assembly Cast Iron Cylinder Assembly Cast Iron Cylinder Assembly Metal Cover
n Non-handed n Non-handed n Non-handed n Non-handed
n Standard n Mounting plate n Mounting plate n Standard
n Includes 4630-3454 Motor n Includes 4630-3454 Motor
Clutch, 4630-3180 I/O Board Clutch, 4630-3180 I/O Board
Assembly and 4630-3462 Assembly and 4630-3462
Controller Controller
n Standard n Same as a 4630-3071 assembly
except on/ off switch is
concealed in endcap and no
hold open switch is included
(Separate key switches
suggested)
n Standard

Track Arm Installation Accessories

4630-3038 4630-3077T 4630-3034
Standard Track Standard Arm Track Roller
n Non-handed n Non-handed n Quiet low friction roller
assembly
n Will not accept hold open clip n Track roller not included
or bumper assembly with arm n Shoulder dimension
n Standard “X” = 1/8˝ (3mm)

G39
