4640
Series
Auto Equalizer

Accessories

Cylinders Cover

4642-3971 4642-3071 4642-3071CS 4640-72MC
Cast Iron Cylinder Assembly Cast Iron Cylinder Assembly Cast Iron Cylinder Assembly Metal Cover
n Non-handed n Non-handed n Non-handed n Non-handed
n Standard n Mounting plate n Mounting plate. n Standard
n Includes; 4640-3454 Motor n Includes; 4640-3454 Motor
Clutch, 4640-3180 I/O Board Clutch, 4640-3180 I/O Board
Assembly and 4640-3462 Assembly and 4640-3462
Controller Controller
n Standard n Same as a 4640-3071 assembly
except on/ off switch is
concealed in endcap and no
hold open switch is included.
(Separate key switches
suggested)
n Standard

Arms

4640-3077 4640-3077L 4640-79 4640-79LR
Regular Arm Long Arm Rod & Shoe Long Rod & Shoe
n Non-handed n Includes LONG ROD AND SHOE, n For use with regular arm n Used for long arm with deep
4640-79LR for deep reveals reveals

G45
LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 01/18
