4640
Series
Auto Equalizer

Ordering Information

How-to-order 4640 Series closers
Closer will be shipped with:
Specify finish - Standard cylinder
Standard Powder Coat __________ - Standard metal cover
Aluminum, Dark Bronze, Statuary, Light Bronze, Black, Brass - Regular arm
- Wood and machine screw pack
unless options listed below are selected
Closer options

Cylinder Assembly
CS (concealed on/off switch)
(separate key switches suggested)

Finishes
Custom Powder Coat (RAL)__________________
Plated Finish, US_____________________________
Arm
Long (LONG)

Screw pack
TB*, Wood & Machine Screw (TBWMS)
TORX Machine Screw (TORX)
TB* & TORX Machine Screw (TBTRX)
*Specify door thickness if other than 1-3/4˝.

Special template
ST- ________

Table of sizes

n Non-sized 4640 series cylinder is adjustable from size 2 through size 5 and is shipped set to size 3
n Closing power of 4640 Series closers may be increased 50%

Exterior (and Vestibule) door width Interior door width
36˝ 42˝ 36˝ 38˝ 48˝ 54˝
914mm 1067mm 914mm 965mm 1219mm 1372mm
size 5 size 3 size 4 size 5
4642 4642
Minimum door width Minimum door width

Indicates recommended range of door width for closer size. NOTE: Minimum door width 36˝ (914 mm).

G47
LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 01/18
