4640
Series
Auto Equalizer

Accessories

Installation Accessories

4640-334 4640-334-2 4640-334CS 4640-3179-1
Switch End Cap Blank End Cap Switch End Cap On/Off Switch Assembly
n End cap (black powder finish coat n Black powder coat only n End cap and switch (black powder n Black rocker switch
only) with cut outs for installing coat only) for concealed switch n Plugs into high voltage PC board
on/off and hold open switches option

4640-3179-2 4640-3180 4640-3454 4640-3462
Hold Open Switch Assembly PC Board Assembly Motor/Clutch Assembly Control Box Assembly
n Black rocker switch n High and low voltage PC boards n A geared assembly in an LCN n Digital controller with built-in
connected to mounting bracket power operator that incorporates 12/24 VDC power supply
n ield wired to low voltage PC board
a “no destruct” feature
n Programming and timing
functions are adjusted on
controller

4640-3498-2 4640-3498-1
AC Power Cable Ribbon Cable Connector
n 2 wire cable to connect 120 VAC n 16 wire ribbon cable connecting
from PC board assembly to 1-24 pin terminal connectors to
controller controller
