4210
Series

Accessories

Cylinder Cover

4211(6)-3071 4210-72MC
Cylinder Assembly Metal Security Cover
n Handed n Handed
n Cast iron n Four point mounting for extra
n Standard security
n Closer adjustments not
accessible with cover installed
n Standard

Arms

4210-3077EDA 4210-3077CNS 4210-3049CNS
®
Extra Duty Arm Cush-N-Stop (CUSH) Arm HCUSH Arm
n Non-handed n Non-handed n Non-handed
n Parallel arm features solid n Parallel arm features solid forged n Parallel arm provides hold-open function
forged steel main arm and steel main arm and forearm with with templated stop/hold-open points
forearm for potentially abusive built-in stop in soffit shoe n Handle controls hold-open function with
installations
n Double slab arm/pinion thumb turn
n Double slab arm/pinion attachment for maximum n HCUSH arm not available with 4216 cylinder
attachment for maximum strength
strength n Double slab arm/pinion attachment for
maximum strength

Installation Accessories

4210-18, 4210-18CUSH 4210-30 4210-61 4210-419
Plate CUSH Shoe Support Blade Stop Spacer PA Flush Panel Adapter
n Required for push side mount n Provides anchorage for fifth n Lowers parallel arm shoe to n Provides horizontal mounting
where top rail is less than 5-1/8˝ screw used with CUSH arms clear 1/2˝ (13 mm) blade stop surface for EDA or CUSH shoe on
(130 mm), measured from the where reveal is less than 3-1/16˝ single rabetted or flush frame
stop (78mm)
n Requires 2˝ (51 mm) minimum
top rail measured from the stop.
n Also used with CUSH arm
installations

F9
