4210
Series

Features

The 4210 SMOOTHEE Series is a heavy duty, high security closer with special components
®
to minimize tampering and vandalism. Forged steel parallel arms and heavy gauge metal
security covers are designed for correctional, vandal prone, institutional and other high
traffic applications. The closer has passed 10 million cycles in independent testing. A choice

of finishes and cylinder functions meet correctional and vandal resistant requirements.

Certifications Grade 1 - ANSI A156.4, UL 10C, ADA*, 100 Hour Cover Metal Security
Salt Spray, Meets BAA - Buy American Act Fasteners TORX machine screw pack
*4211 cylinder meets ADA
Mounting Parallel (Push Side)
Body Construction n Cast Iron Body
n Full Complement Bearing Arms Extra duty, non hold-open
n 1-1/2˝ Diameter Piston Finishes/Colors/ n Aluminum (689)
n 11/16˝ Diameter Double Heat Treated Powder Coat n Statuary Bronze (690)
Pinion Journal n Light Bronze (691)
Fluid All Weather Fluid n Black (693)
n Dark Bronze (695)
Handing Handed n Brass (696)
Size n Adjustable Exterior and, Vestibule, Size 3-5 n Custom colors optional
or size 6 n Optional SRI primer - powder coat only
n Adjustable, Interior, Size 2-5; or size 6
n Optional plated finishes (cover only)
Warranty 15 years

Special Customized installation templates or products may be available to solve unusual applications.
Templates Contact LCN Product Support for assistance.

MOUNTING FINISH COVER CYLINDER *ARM FUNCTION
PARALLEL ARM (PUSH)
DELAYED ACTION
HINGE (PULL) SIDE STOP FACE CONCEALED (FRAME) PLATED PLASTIC METAL HANDED NON-SIZED SIZED ACCESSIBILITY AVB** DPS SWITCH STANDARD (SINGLE) CUSH/HCUSH
POWDER COAT
EDA

180 110

AVAILABLE Closer available with less than 5.0 lbs. opening force on 36˝ door.
NOT AVAILABLE * Maximum opening with standard template. See individual closer series for degrees of opening per installation.
** Advanced Variable Backcheck.

F7
LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 11/16
