2210
Series

Features

The concealed 2210 Series, heavy duty, high security track closer features complete
concealment with special components to minimize tampering and vandalism. Forged
steel, single lever arm and heavy steel mounting plate are designed for correctional, vandal
prone, institutional, and other high traffic applications. A choice of finishes and cylinder

functions meet correctional and vandal resistant requirements.

Certifications Grade 1 - ANSI A156.4, UL 10C, ADA, 100 Hour Cover Metal, standard
Salt Spray, Meets BAA - Buy American Act
Fasteners TORX machine screw pack
Mounting n Concealed, single acting cylinder in head
Body Construction n Cast Iron Body frame
n Full Complement Bearing n Concealed, arm and track in top rail of
n 1-1/2˝ Diameter Piston door
n 11/16˝ Diameter Double Heat Treated Arms Standard security arm and security track
Pinion Journal
Finishes/Colors/ n Aluminum (689)
Powder Coat n Statuary Bronze (690)
n Light Bronze (691)
Fluid All Weather Liquid X Fluid n Black (693)
n Dark Bronze (695)
Handing Handed
n Brass (696)
Size Sized, interior, exterior and vestibule 3-5 n Custom colors optional
(refer to chart)
n Optional SRI primer - powder coat only
Warranty 15 years (2210); 2 years (2210DPS) n Optional plated finishes

Special Customized installation templates or products may be available to solve unusual applications.
Templates Contact LCN Product Support for assistance.

MOUNTING FINISH COVER CYLINDER *ARM FUNCTION
PARALLEL ARM (PUSH)
DELAYED ACTION
HINGE (PULL) SIDE STOP FACE CONCEALED (FRAME) PLATED PLASTIC METAL HANDED NON-SIZED SIZED ACCESSIBILITY AVB** DPS SWITCH STANDARD (SINGLE) CUSH/HCUSH
POWDER COAT
EDA
180

AVAILABLE * Maximum opening with standard template.
NOT AVAILABLE ** Advanced Variable Backcheck.

F3
