4210
Series

Mounting details

Parallel Arm
(Push Side) Mounting

4"
102 mm

5-1/8"
3-1/2" 130 mm
89 mm
2-1/4"
57 mm
A 12-1/4"
311 mm
B 14-1/16" 5-1/2"
357 mm 140 mm

5-1/8"
130 mm
4210-18

Butt Hinges Should not exceed 5˝ (127 mm) in width
Auxiliary Stop Recommended where the door cannot swing 180° or where CUSH arms not used
Clearance For EDA or CUSH is 5-1/2˝ (140 mm) from push side of door
Top Rail Less than 5-1/8˝ (130 mm) measured from stop, requires PLATE 4210-18. Plate requires 2˝ (51 mm) minimum top rail
Stop Width 2-3/4˝ (70 mm) recommended. Less than 1˝ (25mm), consult factory
Delay Action n Add suffix “DEL” to selected cylinder (eg. 4211DEL)
n Not available with 4215 or 4216 cylinder
n Delays closing from maximum opening to approximately 70°
n Delays time adjustable up to approximately 1 minute
Advanced Variable n Cylinder starts backcheck at approximately 45° instead of the normal 75°
Backcheck n Add suffix “AVB” to selected cylinder (eg. 4211 AVB)
Maximum opening CUSH arm can be templated for
EDA arm can be templated for maximum opening at
100°: A = 5-15/16˝ (151 mm) 85°: A = 8-5/16˝ (211 mm)
B = 7-1/4˝ (184 mm) B = 9-5/8˝ (244 mm)
140°: A = 4-7/16˝ (113 mm) 90°: A = 7-11/16˝ (195 mm)
B = 5-3/4˝ (146 mm) B = 9˝ (229 mm)
180°: A = 2-15/16˝ (75 mm) 100°: A = 6-7/16˝ (164 mm)
B = 4-1/4˝ (108 mm) B = 7-3/4˝ (197 mm)
110°: 5-9/16˝ (141 mm)
B = 6-7/8˝ (175 mm)
Hold-open point at maximum opening
with H-CUSH arm.
Options n Delayed Action or Advanced Variable Backcheck cylinder.

F8 LCN Door Control Catalog
