High Security
Series

Product selection guide
High Security LCN closers feature a vandal resistant design engineered for each application, easy
installation, and superior performance. This guide is based on the desired mounting of the closer.

EXTERIOR
DOOR
CONCEALED PUSH SIDE PULL SIDE
IN FRAME MOUNTED MOUNTED

SINGLE PARALLEL DOUBLE
LEVER ARM ARM LEVER ARM
2210 4210 4510
2210 DPS*

INTERIOR
DOOR
CONCEALED PUSH SIDE PULL SIDE
IN FRAME MOUNTED MOUNTED

SINGLE PARALLEL SINGLE DOUBLE SINGLE
LEVER ARM ARM LEVER ARM LEVER ARM LEVER ARM
2210 4210 4210T 4510 4510T
* Door position switch. 2210 DPS*

Product comparison

This chart shows a basic comparison of LCN High Security closers. Refer to the specific closer chapter for complete details.

MOUNTING FINISH COVER CYLINDER **ARM FUNCTION
PARALLEL ARM (PUSH)
HINGE (PULL) SIDE CONCEALED (FRAME) ACCESSIBILITY DPS SWITCH STANDARD (SINGLE) CUSH/HCUSH
DELAYED ACTION
POWDER COAT
CLOSER STOP FACE PLATED PLASTIC METAL HANDED NON-SIZED SIZED AVB*** EDA
SERIES
2210 180
2210DPS 180
4210 180 110
4210T 110
4510 140
4510T 180

AVAILABLE Closer available with less than 5.0 lbs. opening force on 36˝ door.
NOT AVAILABLE ** Maximum opening with standard template. See individual closer series for degrees of opening per installation.
*** Advanced Variable Backcheck.
