4310 HSA
Series

Accessories
WIRING DIAGRAM
INPUT VOLTAGE
24V AC/DC
OR 120V AC/DC
(USUALLY FROM
ALARM PANEL
OR DETECTOR)
Cylinders Cover Track
CHASSIS GROUND

4311HSA-3971 4311HSA-3071 4310HSA-72MC 4310HSA-3038
HSA Cylinder Assembly HSA Cylinder/Plate Assembly Metal Cover Track
n Handed n Handed n Handed n Non-handed
n Cast iron n Includes scanner module and n Standard n Standard
n 24V AC/DC input only for system timer module
holding solenoid n “On/Off” switch assembly
n Standard provides continuous hold-open
function
n 24V AC/DC input only for holding
solenoid and electronics modules
n Standard

3448
Arms Switch Scanner

3351
4310HSA-3077T 4310HSA-3077DE 4310HSA-3448 4310HSA-3428
Standard Arm Double Egress Arm Switch Assembly Scanner Module
n Handed n Handed n Provides continuous hold-open
function
n For double egress doors and
frames n Available in 24V only
n 2 11/16˝ (67 mm) maximum
reveal
n Optional

Installation Accessories

4310HSA-3034 4310HSA-3210
Track Roller Transformer
n Quiet, low friction roller n Reduces line voltage from 120V
assembly to 24V AC
n Shoulder dimension “X” = 1/8˝ n Mounted on plate for 4˝
(3 mm) (102 mm) x 4˝ x 2-1/8˝ (54 mm)
junction box (by others)

E39
LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 07/17
