4410ME
Series
Accessories
WIRING DIAGRAM
INPUT VOLTAGE
24V AC/DC
OR 120V AC/DC
Switch (USUALLY FROM
ALARM PANEL
OR DETECTOR)
24V shown
CHASSIS GROUND
120V shown
4410ME-3351
Switch Assembly
n Provides continuous hold-open
function
n Available as 24V or 120V, please
specify
Installation Accessories
4410ME-18 4410ME-18G 4410ME - 3210 4410ME-3354
Mounting Plate Mounting Plate Transformer ME Wiring Harness
n Standard n Substituted for standard plate on n Reduces line voltage from 120V to n Three wire harness with 6˝
flush ceiling installations 24V AC (152 mm) leads for field wiring
n Optional n Mounted on cover for 4˝ (102 mm) connections
x 4˝ x 2-1/8˝ (54 mm) junction
box (by others)
