Page 208 - Herrajes Patricios - Catalogo LCN

3130SE
Series

Ordering Information How-to-order 3130SE Series closers
Closer will be shipped with:
Select cylinder size - Standard arm
3133SE - Track roller and slider
3134SE - Standard track
- Wood & machine screw pack
Select hand unless options listed below are selected.
RH
LH
Voltage
24V AC/DC
120V AC/DC

Specify finish
Standard Powder Coat __________
Aluminum, Dark Bronze, Statuary, Light Bronze, Black, Brass

Closer options

Arm Installation accessories
Long Arm* (LONG) Transformer, 4040SE-3210
* use with SEL track only
Finishes Screw pack
Custom Powder Coat (RAL) ___________ TORX Machine Screw (TORX)
Plated Finish, US ___________
Special template
ST- ________

Table of sizes

n Select closer based on width of door
n Sized 3130SE series cylinders available in size 3 or 4
n Closing power of all 3130SE Series closers is not adjustable

Interior door width
28˝ 34˝ 38˝ 48˝
711mm 864mm 965mm 1219mm
size 3 size 4
3133SE
3134SE
Minimum door width
NOTE: For SE, minimum door width 28˝ (711mm)
Indicates recommended range of door width for closer size.
For SEL, minimum door width 32˝ (813mm)

E14 LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 07/17
