3130SE
Series

Accessories

Cylinder Arms

3130SE-3071 3130SE-3077T 3130SEL-3077T
SE Cylinder Assembly Standard Arm Long Arm
n Handed n Handed n Handed
n Cast iron n Adjustable to select hold-open n Provides hold-open point from
n For various applications see point 110° to 130°, determined by
track templating
“Table of Sizes” on 3130SE n Standard
Series page 16 n Used with SEL TRACK 3130SEL-
n Standard 3038 only
n Optional
Tracks Installation Accessories

3130SE-3038 3130SEL-3038 3130SE-81 3130SE-3034SE
SE Track SEL Long Track Conduit Quick-Connector Track Roller & Track Slider
n Non-handed n Non-handed n Two piece connector for use n Quiet, low friction roller assembly
n Circuitry accepts either AC or DC n Used with LONG ARM, 3130SEL- with 1/2˝ conduit n Shoulder dimension “X” = 1/8˝
WIRING DIAGRAM
INPUT VOLTAGE input 3077T, only n See page 21 for illustration (3 mm)
24V AC/DC
OR 120V AC/DC n 24V holding solenoid (24) or n Provides hold open point from n Alloy metal slider for use in SE
(USUALLY FROM
ALARM PANEL 120V holding solenoid (120), 110° to 130°, determined by series tracks only
OR DETECTOR)
please specify templating. Circuitry accepts
n Standard either AC or DC input
n 24V holding solenoid (24) or 120V
CHASSIS GROUND
holding solenoid (120), please
specify
n Optional
4040SE-3210
Transformer
Switch n Reduces line voltage from 120V
to 24V AC
n Mounted on plate for 4˝
(102 mm) x 4˝ x 2-1/8˝
(54 mm) junction box (by
others)
3130SE-3436
Test Switch

E13
LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 07/17
