SEM7800
Series

Accessories

Extensions

SEM7810-514 SEM7810-E050 SEM7810-E075 Extension, SEM7810-E100
Coupler Assembly Kit Extension - 1/2˝ Extension - 3/4˝ Extension - 1˝
n Required for each door needing n Metal n Metal n Metal
extension(s)
n Standard n Standard n Standard
n Kit includes coupler link and ball
pivot (alone serves as a 1-1/2˝
extension)

SEM7810-E200 Extension, SEM7810-E400 SEM7810-517
Extension - 2˝ Extension - 4˝ Extension kit
n Metal n Metal Extension kit includes:
n 10 ..........7810SEM-E050
n Standard n Standard
n 10 ...........7810SEM-E075
n 10 ...........7810SEM-E100
n 5 ............7810SEM-E200
n 20 .............7810SEM-514

Note: Using just the Coupler Assembly Kit (SEM7810-514) will create a 1-1/2˝ link.
Extension Links are available in different lengths and can be combined together to achieve the desired length. Max. recommended length = 12˝
