5030
Series

Accessories

Cylinder Arms

5031(3)(4)(5)(6)-3071 5030-3077 5030-3049
Cast Iron Cylinder Assembly Regular Arm Hold-Open Arm
n Handed n Non-handed n Handed
n With mounting plate n Provides hold-open function for
n Standard 100° template, adjustable at
elbow
n Optional

Installation Accessories

5030-416 5030-417
Wood Mounting Clip Set Wood Mounting Clip Set
n Simplifies mounting center n Simplifies mounting offset
pivoted 5030 closer in wood pivoted or butt hung 5030
frame closer in wood frame.
n Includes latch stile clip, hinge n Includes two clips.
stile clip, and cover. n For use with offset pivots.
n For use with Ives Series center n Consult factory for special
pivots
template.
n Consult factory for special
template

D27
