1450
Series

Accessories

Arms

1450-3077 1450-3077L 1450-3049 1450-3049L
Regular Arm w/PA Long Arm Hold-Open Arm w/PA Long Hold-Open Arm
n Non-handed n Non-handed n Non-handed n Non-handed
n Mounts hinge side or top jamb n Includes LONG ROD AND SHOE, n Mounts hinge side, top jamb or n Includes LONG HEAD AND TUBE,
n Includes PA SHOE, 1450-62PA 1450-79LR for top jamb mount parallel arm (62PA required) 1450-3048L for top jamb mount
required for parallel arm mounting with deep reveals n Hold-open adjustable at shoe with deep reveals
n Optional n Optional
n Optional

1450-3077EDA 1450-3077EDA/62G 1450-3049EDA 1450-3077CNS
Extra Duty Arm Extra Duty Arm w/ 62G Hold-Open Extra Duty Arm Cush-n-Stop Arm
®
n Non-handed
n Non-handed n Handed arm n Non-handed
n Features solid forged steel main n Features solid forged steel main n Provides hold-open function n Features solid forged steel main
and forearm for potentially abusive and forearm for potentially abusive adjustable at shoe arm and forearm with stop in soffit
installations installations shoe
n Optional 1450-3077EDA/G for n Optional 1450-3077EDA/G for n Optional n Optional
blade stop clearance
blade stop clearance

1450-3049CNS 1450-3077SCNS 1450-3049SCNS
HCUSH Arm Spring CUSH Arm Spring HCUSH Arm
n Non-handed n Non-handed n Non-handed
n Provides hold-open function with n For abusive applications features n For abusive applications features
templated stop/hold-open points solid forged steel main arm and solid forged steel main arm and
n Handle controls hold-open forearm with spring loaded stop in forearm with spring loaded stop in
function the soffit shoe the soffit shoe
n Optional n Handle controls hold-open
n Optional
function
n Optional

C25
LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 11/16
