1450
Series

Features

The 1450 Series cast aluminum closer was specially designed to deliver consistent, dependable,
long-term performance in frequently-used, low-abusive traffic areas. The patented design,
featuring the industry's most common hole pattern, is an excellent choice for a range of
applications - from aftermarket replacement to aluminum store fronts, to new construction

projects - anywhere quality, reliability and value are important.

Certifications Grade 1 - ANSI A156.4, UL 10C, ADA, 100 Hour Cover n Slim Line Plastic, Standard
Salt Spray, Meets BAA - Buy American Act n Full Plastic and Metal, Optional
Body Construction n Cast Aluminum Body Fasteners Universal Screw Pack (UNIV)
n Full Complement Bearing Mounting Hinge (Pull Side), Top Jamb (Push Side),
n 1-1/4˝ Diameter Piston Parallel Arm (Push Side)
n 5/8˝ Diameter Single Heat Treated
Pinion Journal Arms Standard regular pull side, and top jamb
Fluid All Weather Fluid Finishes/Colors/ n Aluminum (689)
Powder Coat n Statuary Bronze (690)
Handing Non-Handed n Light Bronze (691)
n Black (693)
Templating Peel-n-Stick templates -
3/4˝ x 12˝ Mounting Hole Pattern n Dark Bronze (695)
n Brass (696)
n Custom colors optional
Size Adjustable Spring Size 1-6 n Optional SRI primer - powder coat only
Warranty 25 years

Special Customized installation templates or products may be available to solve unusual applications.
Templates Contact LCN Product Support for assistance.

MOUNTING FINISH COVER CYLINDER *ARM FUNCTION
STANDARD (SINGLE)
DELAYED ACTION
TOP JAMB (PULL)
HINGE (PULL) SIDE TOP JAMB (PUSH) STOP FACE PAINT POWDER COAT PLASTIC METAL NON-HANDED ACCESSIBILITY REGULAR (DOUBLE) HOLD-OPEN * CUSH/HCUSH
SCUSH/SHCUSH
PARALLEL ARM
NON-SIZED
EDA/HEDA *
PLATED
180° 180° 180° 110° 110°
AVAILABLE Closer available with less than 5.0 lbs. opening force on 36˝ door.
NOT AVAILABLE * Maximum opening/hold-open point with standard template.
D = For designer series only.

C19
LCN Door Control Catalog
LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 11/16 fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 11/16
phone: 877-671-7011 n
