Arms 4050

Series

Accessories
4050-3077 4050-3077L 4050-3049
Regular Arm Long Arm Hold-Open Arm
n Non-handed n Non-handed n Non-handed
n Mounts pull side or top jamb with n Includes LONG ROD AND SHOE, n Mounts pull side or top jamb with
shallow reveal 4050-79LR for top jamb mount shallow reveal
n Includes PA SHOE, 4050-62PA n Optional n Hold-open adjustable shoe
required for parallel arm mounting
n 4050 closer includes 4050-62PA
shoe required for parallel arm
mounting
n Optional

4050-3049L 4050-3077EDA 4050-3049EDA
Long Hold-Open Arm Extra Duty Arm Hold-Open Extra Duty Arm
n Non-handed n Non-handed n Handed
n Hold-open adjustable shoe n Features forged, solid steel main n Features forged, solid steel main
and forearm for potentially and forearm for potentially
n Includes LONG HEAD AND TUBE, abusive installations abusive installations
4050-3048L for top jamb mount
n Hold-open function is adjusted at
n Optional
the shoe

4050-3077EDA/62G 4050-3049EDA/62G 4050-3077CNS 4050-3049CNS
®
Extra Duty Arm With 62G Hold-Open Extra Duty Arm With 62G Cush-N-Stop Arm HCUSH Arm
n Non-handed n Handed n Non-handed n Provides hold-open function with
n Features forged, solid steel main n Features forged, solid steel main n Features solid forged steel main templated stop/hold-open points
and forearm for potentially and forearm for potentially arm and forearm with stop in n Handle controls hold-open function
abusive installations abusive installations soffit shoe
n 62G shoe provides additional n 62G shoe provides additional n Optional
blade stop clearance for use with blade stop clearance for use with
additional door hardware such as additional door hardware such as
an overhead holder an overhead holder
n Hold-open function is adjusted at
the shoe

LCN Door Control Catalog B61
