9550
Series
Senior Swing

Accessories

Motor Gearbox Mount Brackets

9550-3454 9550-275 9550-3018 9550-334-1
Motor Gearbox Mounting Bracket Rear Mounting Bracket Angled Bracket
n Senior swing n Motor gearbox mounting n Motor gearbox mounting n Mounting bracket for surface
bracket for 2-3/4˝ offset pivot bracket applications (includes 2
n Handed
or butt hinge installations mounting brackets)
n Driving mechanism for operator
n Front bracket
n Provides maximum 15 lbs
opening force
Control Box Header

9550-3462 9550-982 9550-3572HL
Control Box Companion Cable Header
n Electronic controlling device for n Cable that allows one control n Pair door, two operators
Senior Swing box to run two motor gear n Specify other length 52˝ to 98˝ (Push)
boxes
n Specify other length 60˝ to 98˝ (Pull; Double Egress)
n For use with Senior Swing
n Standard

End Caps

9550-334 9550-334-2
Header End Caps End Dress Plate
n With openings for wiring n Metal finish end cap
