Senior Swing
Unique
Features

Digital Control Suite Programming Mode
Provides exceptionally precise control of a large range of built-in functions Allows tailoring the following functions to meet specific site conditions
combined with superior durability and performance. Visual indications n Opening Speed
and digital readouts of all control function settings and activity make n Backcheck Speed
adjustments easy, fast and accurate.
n Backcheck Position
Dual Independent Program Memories n Hold Open Delay
Each unit is pre-programmed to factory default settings. The installer can n Latch Position
adjust the unit to meet the job site requirements. These field settings are
locked into the computer’s memory. Any subsequent field adjustments n Auto Reverse - Closing
replace the original field adjustments. The factory settings are always n Electric Lock Delay
retained in memory and can be recalled to replace the field settings in just n Power Boost
seconds, restoring the unit to its original programming. n Push N’ Go
On-Board Diagnostics n Alternate Action
Sophisticated built-in diagnostics program monitors the system n Safety Slow/Stop
microprocessor, power supplies, drive systems, actuators and safety circuits. n Slow Down Disable
Reduces the time required to make sure the installation is complete and
correct. Push ‘N Go
Allows pedestrians to walk up to the door and push it open as if it were a
On-Board Power Supply manual door. After the door is manually opened approximately 5 degrees,
Provides 24V AC output or 24V DC output with rectifier to power card the Push ‘N Go feature takes over and continues to open the door – slowly
readers, manual actuators and other peripherals. and automatically to the full open position. With Push ‘N Go, the door
will stay fully open from one to 30 seconds, depending on the time delay
Plug and Play Sensors chosen.
Motion sensors and safety sensors feature a “plug and play” concept
allowing fast and accurate wiring connections in only seconds. Auto Reverse
A safety feature that reverses the direction of the door when it comes into
Electronic Circuit Protection contact with an object during either opening or closing.
High voltage (primary AC input) is protected by replaceable fuse. Low
voltage (secondary AC output) is protected by self-resetting fuses. Safety Slow/Stops Function
Once the door starts opening, any person or object entering the swing area
Visual Function Indicators will cause the door to go into a safety slow speed. This function can be set
LED Display allows direct observation of these inputs while in visual to allow for a short stop once a person or object is sensed.
function indicator mode:
n Key switch- set to Auto, OFF or HOLD Power Boost
Adds an additional latching force to ensure secure latching in severe wind
n Activate
or stack conditions. Power Boost is also ideal for overcoming slowing
n DMSS approach obstacles such as electric strikes. Provides approximately 25 lbs. of total
n DMSS safety closing force.
n Bodyguard Microprocessor
n Power Boost Disable Control unit allows for quiet efficiency in operation. Combined with the all
electromechanical unit, it eliminates unnecessary wear and prolongs the
life of the unit.
Electric Lock Delay
Causes a 1 second delay between activate signal and door opening to allow
time for most electric locks to disengage before operator opens door.
