9130
Series
Benchmark

Accessories

Motor Gearbox Control Box

9130-3454S 9130-3454 9130-3462
Motor Gearbox Assembly Motor Gearbox Assembly Control Box (120v)
(W/O Switch)
n Driving mechanism for operator n Electronic controlling device
(switch included) n Driving mechanism for with power supply output
n For 27˝ unit operator (switch not included) and power boost feature for
n For full length 36˝ unit Benchmark

Brackets

9130-3018 9130-3351-2
Mounting Bracket Switch Bracket
n Standard n 41˝ cable
n Bracket used to locate switch at
end of cover on full length unit
Covers

9130-72MC 9130-72FC 9130-163
Metal Cover Full Metal Cover Cover Insert
n Non-handed n Non-handed n Used to cover operator shaft
opening (includes 2 pieces)
n 27˝ n 36˝
n Extruded aluminum n Extruded aluminum
n Standard

9130-163-1 9130-334
Cover End Cap Insert Cover End Cap
n Used to cover switch hole n Black plastic
opening n Includes 9130-163-1 cover and cap insert

G57
LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 01/18
