P. 318
Benchmark
Unique
Features
On-Board Power Supply Programming Mode
Provides 24V DC output to power card readers, manual actuators and other Allow tailoring of the following functions to meet specific site conditions:
peripherals. n Power Boost
Electronic Circuit Protection n Opening Speed
Fused input circuit protection and fused output protection for 24 VDC n Backcheck Speed
peripherals. n Hold Open Time Delay
n Backcheck Position
Visual Function Indicators
There are 2 LED's for installation and trouble shooting feedback. The motor n Closing Speed
LED will illuminate when the motor drive circuit energizes. This is when the n Latch Position
operator is activated it will remain on only during the opening of the door n Push ‘N Go
and the power LED this will illuminate when power is applied to the board n Delayed Activation
and remains illuminated as long as there is power applied to the board.
