7900
Series
Control Boxes

CONTROL BOXES

Heavy duty, surface mounted control box contains one or two electrically controlled pneumatic circuits. Air filtration, pneumatic
regulation, and system timing is performed by the control box. 7980 Series control boxes also contain a built-in air pump to power the
system. Each pneumatic circuit can be adjusted for a hold open time up to 30 seconds. Output air pressure can be adjusted to precisely
tailor system to individual door requirements.
Pneumatic connections use standard barbed fittings and 925 tubing from the compressor to the control box to the operator. A package
of barbed tee and butt connectors are supplied with each control box to simplify installations. Consult LCN for details. Other than a
semi-annual inspection of the air filter assembly and muffler, no periodic system maintenance is required.

A B
A
A
Timer Timer
Adjust Adjust
Wheel Wheel
LED LED
*Filter *Filter
A B
Earth
5 AMP Ground Earth
Fuse only Ground
Air Pressure
Regulator
Knob
Air Pressure
Regulator
Knob
Air Pressure Air
Gauge Pressure
Gauge
Install box with two tapcon
Manual concrete screws - 3/16" x 1-1/4". Manual
Override Drill 5/32" hole 1-1/4" deep with Override
carbide tipped concrete bit
7901 AND ES7901 CONTROL BOX 7902 AND ES7902 CONTROL BOX
n For single door applications or independent control of single door in n For independent operation of two door or four door leaves, if pairs
multiple door systems are actuated simultaneously
n Two door leaves can be operated, if they are activated n Two independent pneumatic circuits accept Normally Open
simultaneously (N.O.) inputs from hardwired or RF (wireless) actuator/receiver
n The single pneumatic circuit accepts Normally Open (N.O.) inputs combinations
from hardwired or RF (wireless) actuator/receiver combinations n Sequential operation (add suffix “S”) is available for 7902
n The 7901 control box requires a separate compressor n The 7902 control box requires a separate compressor
P A
A

Door Open
Pump Time Delay
Air “On”
Time
Valve LED LED 7981 AND ES7981 CONTROL BOX
P A n Self-contained control box/compressor combination for single door
5 AMP Fuse Only
leaf applications
Earth
Ground n The single pneumatic circuit accepts Normally Open (N.O.) inputs
Regulated from hardwired or RF (wireless) actuator/receiver combinations
Air Output
to Closer n The 7981 control box does not require a separate compressor
Air Filter
Capacitor
Compressor Pump
