Electrohydraulic
Powered
Systems

ELECTRIC AUTO EQUALIZERS n Electronic Circuit Protection
These Auto Equalizer products are an addition to the original pneumatic The high voltage input circuit is protected by a one amp slow blow fuse.
drive system. People moving through a door can use it as a normal rack & The low voltage output circuits by self-resetting fuses.
pinion door closer or, at the touch of a button, open the door automatically. n Visual Function Indicators
An integrated digital control suite provides all electrical control functions.
These self-contained units are suitable for use on single leaf doors or pair of LED’s allow direct observation of these inputs:
doors where each leaf is equipped with an operator. The operator provides - input power
all the control and power elements into a single operator package, only - fire alarm input
some actuators are required to complete the system. - normal trigger (actuator) input
n Introduced in 1995. - sequential trigger (actuator) input
n Two surface mount models available. The 4630 mounts on the pull side - hold open/alternate action (actuator) input
of the door and the 4640 Series mounts on the push side of the door. - lockout timer
n Integrates a modified heavy-duty 4040 Series cast iron cylinder. - safety sensor (clear) input
n 4600 Electric Operators are not approved for smoke evacuation systems.
- safety sensor (active) input
UNIQUE FEATURES n Programming Mode
n Digital Control Box Allows tailoring the following functions to meet specific site conditions:
Provides exceptionally precise control of a large range of built-in functions - hold open time
combined with superior durability and performance. Visual indications - 90° slow down time
and digital readouts of all control function settings and activity make - one shot input [ON or OFF]
adjustments easy, fast and accurate.
n Dual Independent Program Memories - Exterior mode [ON or OFF] function to accommodate momentary
resistance, like wind gusts, during the opening swing.
Each unit is pre-programmed to factory default settings. The installer can
adjust the unit to meet the job site requirements. These field settings are - electric strike delay timer
locked into the computer’s memory. Any subsequent field adjustments - electric strike 3 second power function [ON or OFF]
replace the original field adjustments. The factory settings are always - sequential trigger delay timer
retained in memory and can be recalled to replace the field settings in just - alternate action timer
seconds, restoring the unit to it’s original programming. - lockout timer
n On-Board Diagnostics
Sophisticated built-in diagnostics program monitors the system
microprocessor, power supplies, drive system and actuators circuitry.
Reduces the time required to make sure the installation is complete and
correct.
n On-Board Power Supply
Provides both 12V DC and 24V DC outputs to power card readers, manual
actuators and other peripherals.
n “No Destruct” Drive System
Specially designed motor and clutch assembly provide a ‘breakaway’
function that reduces the chance the operator will be damaged in an
abusive application. If a vandal tries to force the door closed while it is
trying to open, the clutch mechanism prevents damage. The door is never
out of control because the heavy duty 4040 closer is always operable.
