Electrohydraulic
Powered
Systems

ELECTRIC AUTO EQUALIZER SYSTEMS WARRANTY
n Originally introduced in 1995. n 2 year limited warranty. See General Information Section for complete
n Exceeds proposed ANSI cycle test standard of 300,000 full load details.
automatic operating cycles. Integrated LCN 10 million cycle heavy duty
4040 door closer. MAINTENANCE
n Operators mounted according to the LCN installation instructions require
n Power operation plus full door control.
no periodic maintenance or adjustments.
n For all applications, single or multi-door projects.
n Periodic visual inspections are recommended.
n Opening time to backcheck no faster than 3 seconds.
n No service contracts.
n Opening time 4 seconds or more to fully open.
n Must remain fully open for at least 5 seconds.
n Closing time from 90° to 10° no faster than 3 seconds.
n Less than 15 pounds-force to stop door’s motion.
n Kinetic energy must not exceed 1.25 lbf-ft.
n In event of failure; less than 15 lbf. to release latch, less than 30 lbf. to put
door in motion, less than 15 lbf. to fully open door systems.
STANDARDS, LISTINGS & APPROVALS
n UL listed for Fire Door Operator (GUJY) and Door Operator System
(+DDR) file R18222.
n Tested and certified under ANSI Standard A156.19. Refer to Section 2.1 and
consult factory for details.
n ANSI Standard A117.1, Section 4.13.13.
n ADA law, Section 4.13.12.
n Listed for positive pressure plus UL 10B and UL 10C.
n Wiring is compliant with both UL 325 and the NEC. Separation of high and
low voltage.
n Consult the factory for other listings such as; State and Local Government
regulations.
n UL 10 C Listed for Fire Rated Door Operators with Automatic Closers, File
No. (GUJY).

G33
