4840
Series
Auto Equalizer

Ordering Information

How-to-order 4840 Series closers
Closer will be shipped with:
Specify finish - Standard cylinder
Standard Powder Coat __________ - Standard metal cover
Aluminum, Dark Bronze, Statuary, Light Bronze, Black, Brass - Extra duty arm
- Wood and machine screw pack
unless options listed below are selected
Closer options

Finishes
Custom Powder Coat (RAL)__________________
Plated Finish, US_____________________________

Arm
CUSH-N-STOP (CUSH)
SPRING CUSH (SCUSH)

Screw pack
TB*, Wood & Machine Screw (TBWMS)
*Specify door thickness if other than 1-3/4˝.˝

Installation accessories
Cush Shoe Support, 4840-30
Blade Stop Spacer, 4840-61
PA Flush Panel Adapter, 4840-419
Door Loop Kit, 4840-459
Pneumatic Transfer Hinge, 4840-460
Special template
ST- ________

Table of sizes

n Non-sized 4841 cylinder is adjustable from size 1 through size 5 and is shipped set to size 3
n Closing power of 4841 closers may be increased 50%

Exterior (and Vestibule) door width Interior door width
24˝ 30˝ 36˝ 42˝ 24˝ 34˝ 38˝ 48˝ 54˝
610mm 762mm 914mm 1067mm 610mm 864mm 965mm 1219mm 1372mm
size 3 size 4 size 5 size 2 size 3 size 4 size 5
4841 4841
Minimum door width Minimum door width

Indicates recommended range of door width for closer size.

G27
