Fire/Life
Safety Closers/
Holders Series

SENTRONIC CLOSER/HOLDERS LISTINGS AND APPROVALS
®
Automatic detection and containment of fire and smoke are the best ways Sentronic closer/holders are listed by Underwriters Laboratories, Inc. in
to minimize danger to life and property. Patented Sentronic door closer/ the following product categories under FIRE DOORS (GSNV), Combination
holders are designed to hold swinging doors open in normal use and release Door Closers and Holders (GTIS) file R7050. SEM 7800 Series magnets are
and automatically close the doors under fire conditions. Conforms to major listed under Door Holders (GTPR) file R8327.
building codes, life safety codes (eg. NFPA 101) and ANSI A156.15. Consult the factory for other listings, such as; cUL, Department of Labor
and Industry of the Commonwealth of Pennsylvania, The Board of
SINGLE POINT HOLD-OPEN (SE) Standards and Appeals of the City of New York, Fire and Panic Safety
SE Series offers adjustable single point hold-open function controlled by Standards of the California State Fire Marshal.
solenoid assembly located in the SE track.
HOLDING SOLENOIDS CURRENT DRAW
MULTI-POINT HOLD-OPEN (ME) SE/ME
ME Series offers infinitely adjustable, multi-point hold-open function 24V AC/DC (+10% -15%) @ 90 mA max.
controlled by solenoid on the cylinder assembly. 120V AC/DC (+10% -15%) @ 30 mA max.

HOLDER SCANNER ACTIVATED (HSA) SEM (TRI-VOLT)
Electronically controlled closer/ holder designed to provide easy passage for 12V DC (+10% -15%) @ 30 mA max.
groups of pedestrians through high traffic doors. Best suited for high traffic 24V AC/DC (+10% -15%) @ 20 mA max.
emergency exit doors. 120V AC (+10% -15%) @ 20 mA max.
HSA
MAGNETS (SEM) - ELECTROMAGNETIC DOOR HOLDERS 24V AC/DC (+10% -15%) @ 120 mA max.
SEM Series magnets work with manual door closers to provide single point
hold-open. Now available in new tri-voltage with 35 lbs. of holding force. TRANSFORMER DATA
120V AC 50-60 Hz (primary); 24V AC @ 400 mA max. (secondary)
APPLICATIONS An LCN supplied transformer will power (recommended) 2 SE, 3
n For fire and smoke barrier doors. SE/ME, and 15 SEM.
n Integrated into larger system. ME WIRING
n Surface and concealed mountings. ME “ON/OFF” switch assembly includes trim pot to adjust pull out
n Remote control hold-open function of executive and conference area force and fuse to protect solenoid.
doors.
n Adapter plates and other installation accessories available for unusual
conditions.
Input Wires Wire Harness Connector Rectifier Capacitor
(24V Only)
GENERAL NOTES (18 Gauge Black)
Note 1: For installations where 120V AC input voltage is supplied, 120V/24V
transformer, 4040SE-3210, is required to reduce line voltage for 24V
holding solenoid. Units are available in either 24V or 120V input, please
specify. Earth Ground
Note 2: Transformer 4040SE-3210 mounted on cover plate to fit 4˝ (102 mm) (Green) Solenoid
x 4˝ x 2-1/8˝ (54 mm) junction box (by others). On/Off Switch Power Plug
Note 3: SE track quick-connector is required for 1/2˝ conduit. Solenoid Holding Force
Adjustment Potentiometer (24V Only)
Note 4: SE test switch assembly includes fuse to protect solenoid. Works with
ionization, photoelectric and heat sensing detectors (by others). ME (4310, 4410) WIRING DIAGRAM (24V only)

WIRING DIAGRAM
To either terminal
Input voltage 24V AC/DC
or 120V AC/DC
INPUT WIRES (usually from alarm
panel or detector)
To either terminal
Green ground
Terminal
Chassis Ground
SE WIRING DIAGRAM ME (2310) WIRING DIAGRAM

E2 LCN Door Control Catalog
