3130
Series

Ordering Information How-to-order 3130 Series closers
Closer will be shipped with:
Select cylinder size - Standard cylinder with mounting bracket
3131 - Standard arm wtih finish plate
3132 - Standard track
3133 - Wood and machine screw pack
unless options listed below are selected.
Select hand
RH
LH

Specify finish
Standard Powder Coat __________
Aluminum, Dark Bronze, Statuary, Light Bronze, Black, Brass.

Closer options

Track Screw pack
Standard with Bumper (BUMPER) TORX Machine Screw (TORX)
Hold-open (H)
Hold-open with Bumper (HBUMPER)
Special template
Finishes ST- ________
Custom Powder Coat (RAL)___________
Plated Finish, US ______________
SRI primer (use with powder coat finishes only)

Table of sizes

n Select closer based on width of door.
n 3130 Series cylinders available in size 1, 2, or 3.
n Closing power of 3130 Series closers is not adjustable

Interior door width
26˝ 34˝ 38˝
660mm 864mm 965mm
size 2 size 3
3132
3133
Minimum door width

Indicates recommended range of door width for closer size.

Reduced opening force 3130 Series closers
CAUTION ! Any manual door closer, including those certified by BHMA to conform to ANSI Standard A156.4, that is selected, installed and adjusted based
on ADA or other reduced opening force requirements may not provide sufficient power to reliably close and latch a door.
Refer to POWER OPERATORS section for information on DOOR WIDTH 36˝ 42˝ 48˝
systems that meet reduced opening force requirements
without affecting closing power. 8.5* lbs. N/A N/A N/A
* Maximum opening force. 5.0* lbs. 3131 3131 3132

D20 LCN Door Control Catalog
