1460T
Series

How-to-order 1460T Series closers Closer will be shipped with: Accessories
1. Select cylinder size - Standard cover
1461T (adjustable from size 1 to 2) - Standard arm
1460T (adjustable from size 2 to 4) - Standard track
2. Select finish - Track roller
Standard Powder Coat __________ - Self-reaming and tapping screws
Aluminum, Dark Bronze, Statuary, unless options listed below are selected.
Light Bronze, Black, Brass

Closer options

Cover Optional screw packs Special template
Full cover (FC) TB* w/Self-Reaming and Tapping Screws ST- ________
Designer Series metal cover (DS) (TBSRT)
Finish Wood & Machine Screw (WMS)
Custom Powder Coat (RAL) ___________ TB*, Wood & Machine Screw (TBWMS)
(DS cover required) TORX Machine Screw (TORX)
Plated Finish, US ___________ TB* & TORX Machine Screw (TBTRX)
(DS cover required) * Specify door thickness if other than 1-3/4˝
SRI primer (for use with powder coat finishes only) Installation accessories
Track Plate, 1460T-18
Standard with Bumper (BUMPER) Plate, 1460T-18DS1
Hold-Open (H) Plate, 1460T-18FC
Hold-Open with Bumper (HBUMPER) Plate, 1460T-18PA
Plate, 1460T-18PADS1
Plate, 1460T-18PAFC

Table of sizes

n Select closer based on width of door. The spring power of a 1460T cylinder is adjustable from size 2 to
size 4 and is shipped adjusted to size 3
n The closing power of 1460T series cylinders may be increased 50%
n The spring power of a 1461T cylinder is adjustable from size 1 to size 2 and is shipped adjusted to size 1

Interior door width Interior door width
26˝ 34˝ 38˝ 48˝ 26˝ 34˝
660mm 864mm 965mm 1219mm 660mm 864mm
*1460T size 2 size 3 size 4 *1461T size 2

Minimum door width Minimum door width
Indicates recommended range of door width for closer size. Indicates recommended range of door width for closer size.
*Adjustable Size 2 thru 4 *Adjustable Size 1 thru 2

Reduced opening force 1460T Series closers
CAUTION ! Any manual door closer, including those certified by BHMA to conform to ANSI Standard A156.4, that is selected, installed and adjusted based
on ADA or other reduced opening force requirements may not provide sufficient power to reliably close and latch a door.
Refer to POWER OPERATORS section for information on DOOR WIDTH 36˝ 42˝ 48˝
systems that meet reduced opening force requirements
without affecting closing power. 8.5* lbs. N/A N/A N/A
* Maximum opening force. 5.0* lbs. 1461T 1461T 1461T

C41
LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 11/16
