1250
Series

Features

The 1250 Series cast aluminum closer is designed for low-frequency and low abusive traffic
areas. This cast aluminum closer is ideal for aluminum storefronts, interior offices and many
other applications. Combining dependable operation, low maintenance and a patented stylish
look - with or without the optional slim line cover. And with the most common hole pattern in

the industry, the 1250 Series is the perfect choice for easy aftermarket replacement.

Certifications Grade 1 - ANSI A156.4, UL 10C, ADA, 100 Hour Cover n Slim Line Cover, Optional
Salt Spray, Meets BAA - Buy American Act
Fasteners Universal Screw Pack (UNIV)
Body Construction n Cast Aluminum Body Mounting Hinge (Pull Side), Top Jamb (Push Side),
n Full Complement Bearing Parallel Arm (Push Side)
n 1-3/8˝ Diameter Piston Arms Tripack includes Regular, Top Jamb, and
n 5/8˝ Diameter Single Heat Treated Parallel Arm (Rw/PA)
Pinion Journal
Finishes/Colors/ n Aluminum (689)
Fluid All Weather Fluid
Powder Coat n Statuary Bronze (690)
Handing Non-Handed n Light Bronze (691)
n Black (693)
Templating Peel-n-Stick templates -
3/4˝ x 9-1/16˝ Mounting Hole Pattern n Dark Bronze (695)
n Brass (696)
Size Adjustable Spring Size 1-5 n Custom colors optional
Warranty 15 years n Optional SRI primer - powder coat only

Special Customized installation templates or products may be available to solve unusual applications.
Templates Contact LCN Product Support for assistance.

MOUNTING FINISH COVER CYLINDER *ARM FUNCTION
STANDARD (SINGLE)
DELAYED ACTION
TOP JAMB (PULL)
HINGE (PULL) SIDE TOP JAMB (PUSH) STOP FACE PAINT POWDER COAT PLASTIC METAL NON-HANDED ACCESSIBILITY REGULAR (DOUBLE) HEAVY DUTY EDA/HEDA CUSH/HCUSH
SCUSH/SHCUSH
PARALLEL ARM
HOLD-OPEN
NON-SIZED
PLATED
180° 180° 180° 110° 110°
AVAILABLE Closer available with less than 5.0 lbs. opening force on 36˝ door.
NOT AVAILABLE * Maximum opening/hold-open point with standard template.

C3
LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 11/16
