1000 Series
surface
mounted
closers

APPLICATIONS n Painted finishes on cast aluminum closers (1250, 1450).
n For aluminum, hollow metal, or wood swinging doors and frames. n For installations where a higher level of corrosion resistance is
n Can be used with hinge or pivot mounted door. required, LCN offers an optional special rust inhibiting (SRI) pre-
n Mounts on 1-3/4˝ transom without adapter plates. treatment (cast iron). Closers that combine the exclusive LCN powder
n Adapter plates and other installation accessories available for coat finish and the SRI pre-treatment exceed the ANSI standard for
unusual conditions. corrosion resistance even further.
n Plated finishes are available as an option to accent door and frame
FEATURES COMMON TO 1000 SERIES for the 1460 Series closers.
n 1000 series closers mount three ways. Closers with regular or hold-
open arm mount hinge side or top jamb. Parallel arm, closers include - LISTINGS & APPROVALS
62PA SHOE required for parallel arm mount. 1460T mounts hinge side, UL listed for self-closing doors without hold-open under “SWINGING
top jamb (pull side) and stop face. DOOR CLOSERS” (GVEV) file R 1943. Tested and certified under ANSI
n Non-handed for right and left swinging doors. Standard A156.4 grade one. Consult factory for details.
n Closers to meet ADA reduced opening force requirements. Consult factory for other listings such as; cUL, California State Fire
n Adjustable hydraulic backcheck cushions opening swing prior to 90°. Marshal, Bureau of Standards and Appeals.
n Separate regulation of general closing speed and latching speed. POSITIVE PRESSURE
n Joints in arm and shoe adapt to uneven trim. LCN closers have been certified for three hours by UL to be in compliance
n Reversible shoe to boost latching power on double lever arms.
with UL 10 C. Contact LCN for specific details on door closer fire ratings.
DESIGN ASSISTANCE
LCN has been providing reliable solutions to unique door control problems FASTENERS
since 1925. Design and specification assistance are only a phone call away. 1260, 1460, 1460T series closers are shipped with: A standard
Contact LCN for assistance or technical information at 877-671-7011 SELF-REAMING and TAPPING SCREW (SRT) pack that contains
Philips head SRT screws to install the closer. 1250 and 1450 series closers
or FAX 800-248-1460 (Order Entry), Fax 815-879-1495 for are shipped with: A universal screw pack to include self reaming and
Product Support.
tapping screws (SRT), machine screws and wood screws. Standard LCN
WARRANTY thru bolts (TB) can be installed on 1-3/4˝ (44 mm) thick doors with
n 30 year limited warranty (1460 Series) and 20 year limited warranty 1/4-20 machine screws. Optional thru bolt (TB) sizes are available
(1260 Series) on cast iron closers. for 1-5/8˝ (41 mm) or 1-3/8˝ (35 mm) door thickness, but this
n 15 year limited warranty (1250 series) and 25 year limited warranty must be specified when ordering.
(1450 series) on cast aluminum closers.
See General Information Section for complete warranty details.
SPECIFICATIONS
Refer to “SPECIFICATIONS” section for suggested architectural
specifications.
Drill 25/64˝ for
MATERIALS steel doors
n High strength cast iron (1260, 1460, 1460T) or cast aluminum or
(1250, 1450) cylinder. Drill 3/8˝
n Forged steel main arm for all EDA, Cush, 1460HD and 1460T Arms. for wood doors
n One piece forged steel piston.
n Heat treated pinion. Notes:
n LCN's standard all weather fluid performs to temperature ranges 1. For Thru Bolts, specify door thickness if other than 1-3/4˝ (44 mm). Represented in diagram
from 120°F (49°C) to -30°F (-35°C). as dimension “X”.
n High efficiency, full complement, low friction bearings. 2. Phillips head, metric machine screws are available, please specify.
n Tamper resistant regulating screws. 3. LCN recommends the use of wood screws in wood door applications.
n Full rack and pinion hydraulic action. MAINTENANCE
n Quiet, low friction track and roller combination for all single lever arm Closers mounted according to LCN installation instructions require no
closers. periodic maintenance or adjustments..
FINISHES
n Available in six standard or a wide selection of optional custom
powder coat finishes to blend with door and frame.
n LCN’s powder coat finish surpasses 100 hours of salt spray which is
over four times the ANSI standard for corrosion resistance.

C2 LCN Door Control Catalog
phone: 877-671-7011 n fax: 800-248-1460 n www.allegion.com/us n 009426 rev. 11/16
