Track Rail Arm (Pull) Application

D-4550 / D-4551 Series Door Closer Specifications
• T, HT, TCS Application
• Custom installation template may be available for unusual
installation conditions. Contact dormakaba for assistance.
Maximum Door Opening
120° Opening

Hold Open Device 1 2 3
Hold Open Angle 106˚ 86˚ 80˚

D-4550/D-4551 Track Rail Arm Application

Track Rail Arm Pull Installation

Frame 1 2 3 Door

1-11/32” 1-5/32”
34 mm 21-1/32” 1-5/32” 30 mm 29 mm
534 mm 23/32” 18 mm Frame

3-13/16” 97mm 3-7/8” 98mm 1/8” 3mm Door

5-19/32” 13-1/32” 2-7/16”
142 mm 331 mm 62 mm

Drop Plate Installation P45-180 (For drop plate dimensions see page 13.)
Frame

21-1/32”
534mm
1-3/4” 20-1/4”
44mm 514mm 13/16” 21mm Frame

1/2”–13mm
23/32” 18mm 3-13/16” 97mm 2-1/2” 64mm 11/16” 1/8” 3mm Door
18mm

7/8”
22mm
6”
7-5/8” 152mm 1-1/2”
194mm 9” 38mm 1/4”
229mm 6mm
