ELECTRONIC ACCESS CONTROL COMPONENTS ELECTROMAGNETIC LOCKS
EMSL-2000 MICRO SHEAR
& EMSL-2700 HIGH SHEAR LOCKS
—

The EMSL-2000 Series Micro Reliable performance is inherent in
Shear and EMSL-2700 Series this design for high frequency
High Shear locks use an innovative openings.
locking design that incorporates a
special alloy steel for greater Models Available with Built-in
durability and strength. Field Adjustable Auto-Relock
Switch
The field adjustment capabilities The model 2062 and 2766 shear Complete Monitoring Capabilities Listings & Approvals
of these advanced locks ensure locks fit in 1-1/4" face frames and Built-in door position and lock UL/CUL listed under
proper operation after final are equipped with an auto-relock status sensors are available for their continuing
installation alignment. The EMSL switch and external field interface with control and reinspection programs.
Series shear locks also offer a field adjustable time delay of 1–5 annunciator panels or other
adjustable 1 to 5 second auto- seconds after the door is closed. signaling applications. GWXT—Auxiliary Locks
relock delay timer. The 2061 and 2765 fit in a 1-3/4" CVXJ—Burglary-Resistant,
face frame. The 2061 and 2765 Features Electrically Operated Door Locking
The patented EMSL-2000 Series are equipped with a built-in auto . Lateral and vertical field Mechanism
Micro Shear design, with models relock switch and field adjustable adjustment allows precise
2061 and 2062, has surpassed time delay that suspends relocking adjustment of lock and
2000 pounds tensile holding 1–5 seconds after door closure. armature. Electrical Specifications
strength on laboratory tests and This feature ensures that the door . Special alloy steel shear stops. . Voltage: Dual, 12/24 VDC
will withstand forces that will is at rest and fully closed to obtain . Magnetic force is not (field selectable).
deform a door before the lock will optimum alignment before the lock compromised due to profiling of . Wiring: Inboard Terminals.
separate. The 2765 and 2766 is energized. the magnet or armature. . Surge Protection: Built-in Surge
High Shear models surpass 2700 . Built-in field adjustable auto- Protection.
pounds. This design combines Single or Center relock switch.
aesthetics, high security, and Hung Single Acting . Models 2061 and 2765 have an Finishes
performance. With the most Models are available for use with external field adjustable auto-
advanced features in shear lock single- or single acting center hung relock delay timer. Standard Finishes
design, the EMSL-2000 and doors. Several mounting . Compact design allows . Surface Housing—
EMSL-2700 Series create the assemblies are available to meet installation in 1-1/4" or 1-3/4" Aluminum: 628 (Anodized)
ultimate in fail-safe performance varying door and frame face frames. . Mortise Housing—
and security. applications, such as aluminum, . Operates on 12 VDC or 24 VDC. Nickel: 619 (Satin)
. Fail-safe function.
hollow metal, glass, and wood
Lateral & Vertical doors. These locks are also ideally . Built-in voltage kickback Optional Sprayed Finishes

Alignment Adjustment suited for narrow stile glass protection. . Bronze: 710 (Dark)
The exclusive lateral armature entrance doors and frames. . Bond sensor and door position . Black: 711
alignment adjustment can monitoring options without need
compensate for minor warped or Positive Fail-Safe Security for additional holes in the Optional Plated Finishes
misaligned doors. Optimum The shear locks are inherently fail- frame. . Brass: 605 (Bright)
vertical armature positioning is safe. When power is off, the unit is . Compatible with single acting or 606 (Satin)
also obtained with the field unlocked. They are ideal for fire/ aluminum, hollow metal, wood, . Bronze: 611 (Bright)
adjustable design to help insure life safety applications and are or glass doors. or 612 (Satin)
positive relocking of the door compatible with fire alarm . Chrome: 625 (Bright)
without the use of shims. systems, access controls, or 626 (Satin)
mantraps, automatic doors, and
interlock systems.
Mechanical Specifications
Model Holding Force Voltage/Current Lock Dimensions Armature Dimensions
2061 650 MA @ 12 VDC/ 8" L × 1-1/2" W × 1-5/8" D 8-7/16" L × 1-1/2" W × 7/8" D
2000 lb
2062 350 MA @ 24 VDC 8" L × 1-1/2" W × 1-1/8" D 8-7/16" L × 1-1/2" W × 7/8" D
2765 800 MA @ 12 VDC/ 10-7/16" L × 1-1/2" W × 1-5/8" D 11" L × 1-1/2" W × 7/8" D
2700 lb
2766 400 MA @ 24 VDC 10-7/16" L × 1-1/2" W × 1-1/8" D 11" L × 1-1/2" W × 7/8" D
30 DORMA
