ELECTRONIC ACCESS CONTROL COMPONENTS PUSH BUTTONS
ILLUMINATED PUSH BUTTONS
—

DORMA offers illuminated push . PB72 & PB73—1 MO SPST
buttons with LED or incandescent NO, 1 MO SPST NC, 10 A @
bulbs for a variety of access 125 VAC
control solutions.

Timer Accessory Specifications
Square, Illuminated push buttons . Adjustable: MO SPST NO/NC
with interchangable messages ADJ 1−30 sec, 2 A @ 30 VDC
including: . Fixed: MO SPST NO/NC Fixed
. Red Exit 30 sec, 2 A @ 30 VDC
. Green Exit
. Red Push to Exit Finishes PB72/
. Blue Handicap Symbol . Aluminum: 628 PB73
. Spanish of above (Clear Anodized)
. Bronze: 710 (Dark Anodized)
Button Specifications
. PB75—1"×1" square Screws
push button All switches include tamperproof
. PB72 & PB73—2" ×2" screws and driver bit.
square push buttons
Mounting Options
Switch Specifications . All switches below are surface
. PB75-MO—1 MO SPST NO, 1 mount. PB75
MO SPST NC, 6 A @ 125 VAC . Accessory box available below
for single gang surface mount.

3 1-1/2
(76.2) (38.1)

3-1/4
(82.6) 2
3-1/4 (50.8)
(82.6) 4-1/2
(114.3)
4-3/4
(120.7)

2-3/4 11/16 1-15/16
(69.9) (17.5) (49.2)
PB75 1/4 PB72/PB73
(6.4)

Available Items
Item Button Faceplate Switch Faceplate Finish PB 72 1 MO 628
PB BH 2 MO 628
PB 721 MO 630 2" × 2" Single Gang Momentary Brushed Stainless Series
Series
PB 731 MO 630 2" × 2" LED Single Gang Momentary Brushed Stainless Button
Button
PB 752 MO 628 1" × 1" LED Narrow Momentary Brushed Aluminum Faceplate
Faceplate
PB 752 MO 710 1" × 1" LED Narrow Momentary Dark Bronze Switch
Switch
Accessories Faceplate Finish Faceplate Finish
Item Description
TD-ADJ Field Selectable Timer—0−30 seconds—wire inline
TD-FIX Fixed Timer—30 seconds—wire inline
SBX Surface mounting box, single gang—PB721 MO 630 SBX
DORMA 35
