8310
Series

Automatic Operator Actuators & Accessories Auto Operator
Actuators &
Accessories

6˝ Surface and Flush
Mounts

8310-852 8310-852T
Wall Mounted Actuator Wall Mounted Actuator
n Hardwired low voltage actuator with round, stainless steel touch plate in 6˝ n Same as the 8310-852, with the
(152mm) diameter added engraving of “Push to
Open”
n Engraved blue filled handicap symbol conforms to most accessibility codes
n Designed to mount in a flush or surface mount box (sold separately) in/on a
vertical surface near the controlled door
n Optional mounting in single gang electrical box (by others) or double gang
box (4˝ x 4˝ by others)
n Heavy industrial grade components provide vandal resistant mounting and
weather resistant switch standard.

8310-852WP 8310-852TWP 8310-869F
Wall Mounted Actuator Wall Mounted Actuator Flush Mount Box
n Wireless, low profile, low voltage actuator with round, stainless steel touch n Same as the 8310-852WP, with n Rugged Plastic Box, 6˝ Round
plate in 6˝ (152mm) diameter the added engraving of “Push to
Open” n Optional accessory - can be
n Engraved blue filled handicap symbol conforms to most accessibility codes used w/ any 6˝ round actuator
n Surface mount box includes integral transmitter w/ battery and actuator
switch
n Heavy industrial grade components provide vandal resistant mounting and
weather resistant switch standard
n Requires 8310-865 Receiver

8310-869S 8310-802
Surface Mount Box Weather/Trim Ring
n Rugged Plastic Box, 6˝ Round n Plastic Weather/Trim Ring, 6˝
n Optional accessory - can be used Round
w/ any 6˝ round actuator n Optional accessory - can be
used w/ any 6˝ round plastic
mounting box.

8310-8/444 8310/-865 8310-876
Transmitter Receiver Escutcheon
n Transmitter, Wireless, 1 Channel, n Receiver, Wireless, 1 Channel, w/ n Tapered stainless steel escutcheon covers the gap between the wall and
9v battery included Sequencing Feature the back of the wall plate actuators when mounted in electrical boxes (by
n Use to convert standard wall n Used in conjunction w/ Wireless others) to minimize cart damage or vandalism
mount actuator to wireless Actuators & Transmitter(s) n Optional accessory - Can be used w/ any 6˝ round actuator
n Requires 8310-865 Receiver n Not to be used with wireless function

G117
